Getting Started
1. Upload your waveform data files by dragging them into the drop area or clicking to select files.
Working with Waveforms
- Switch between different waveforms using the tabs on the left.
- Adjust Y-axis settings using the controls provided.
- For DC waveforms, use the interruption cycle controls to add shading patterns.
Adding Annotations
- Hold the 'Z' key and click on the graph to add annotations.
- Click existing annotations to edit or delete them.
Exporting
- Exports will save the graph exactly as shown on screen.
Need Additional Help?
Contact us at customertools@lsconsulting.com
Our cathodic protection team can provide personalized support to interpret your data.
Interruption Cycle Controls
- Int Cycle 1 (Gray): Automatically detected ON/OFF periods
- Int Cycle 2 (Blue): User-defined shading pattern
- Select Starting State (ON or OFF)
- Enter ON time in seconds (must be greater than 0)
- Enter OFF time in seconds (must be 0 or greater)
- Toggle switch to apply/remove shading
- Int Cycle 3 (Gold): Additional user-defined pattern
- Works the same way as Int Cycle 2
- Useful for comparing different interruption patterns
Y-Axis Settings
- Upper Value: Set maximum voltage value
- Lower Value: Set minimum voltage value
- Number of Ticks: Adjust grid line density (2-20)
- Use Apply to update changes or Reset to return to auto-scaling
Annotations
- Add: Hold 'Z' key and left-click on the graph
- Edit: Click on existing annotation
- Move: Click and drag annotation box
- Delete: Click annotation and use Delete button
Export Options
- Export Current Tab: Save current graph as PDF
- Export All: Save all tabs as separate PDFs
